Industrial Ethylene Oxide Sterilizers
Industrial Ethylene Oxide Sterilizers
Industrial Ethylene Oxide Sterilizers
Industrial Ethylene Oxide Sterilizers
Industrial Ethylene Oxide Sterilizers
Industrial Ethylene Oxide Sterilizers
Industrial Ethylene Oxide Sterilizers

Industrial Ethylene Oxide Sterilizers

FIRSTEO Industrial Type of Ethylene Oxide Sterilizer is the fastest way to sterilize equipment that is heat-sensitive or susceptible to moisture. Sterilization can be performed for equipment in its original packaging and does not need extra packaging. Sterilizers using EtO cylinders which are available on the market(Our software can be set according to the concentration of ethylene oxide gas used) and allows loading of goods by pallets. A pair of pneumatic automatic sliding doors provides easy loading and unloading. We clean the chamber by forced air circulation after the post-operation. The inflatable silicone gasket eliminates the risks of gas leakage which occurs by air pressure. System testing for gas leakage under vacuum conditions per cycle provides full security.  Our Industrial Type of Ethylene Oxide Sterilizers can work under negative and positive pressures. Temperature, Time, Pressure, Humidity data recording, saving, and printing online.

click here for the details.

Share
Paramter

Primary Technical Parameters

The volume of the inner container

 1、3、6、10、15、20......100m3

Material of case body

 stainless steel

Sterilizing temperature

 0-100°C, PID adjustable

Sterilizing pressure

 -85- + 80KPa

Sterilizing humidity

 30-100%RH

EO ( EtO) concentration

 300-1000mg/L

Sterilizing time

 3-12hrs

Pre-vacuum

-85KPa

Times of air change

 Arbitrarily

Ventilation time

 Arbitrarily

Max electrical heating power

 9-60Kw

Max steam heating power

 3-10Kw

Power source

 3-phase, 5-wire, 380V 50Hz/ 60Hz


SPECIFICATIONS

OUTSIDE SIZE mm

TRANSPORT SIZE mm

INSIDE SIZE mm

NET VOLUM m3

FST-(50-100)

_——

——

Designed according to users

50-100

FST-40

13000X3100X4100

13000X2050X3100

12500X1500X2200

41.25

FST-35

11500X3100X4100

11500X2050X3100

11000X1500X2200

36.3

FST-30

11500X2950X3900

11500X1900X2900

11000X1350X2050

30.44

FST-25

10000X2950X3800

10000X1900X2800

9500X1350X1950

25.01

FST-20

9450X2950X2875

9450X1900X2400

9000X1350X1700

20.655

FST-15

7200X2950X2875

7200X1900X2400

6750X1350X1700

15.491

FST-10

4950X2950X2875

4950X1900X2400

4500X1350X1700

10.328

FST-06

3250X2950X2875

3250X1900X2400

2800X1350X1700

6.426

FST-03

2300X2300X2700

2300X1550X2350

1850X1000X1670

3.089

FST-01

1750X1700X1750

1750X1700X1750

1500X700X1000

1.05



Product Details:

FIRSTEO Machinery
Equipment Co., Ltd.

FIRSTEO Machinery Equipment Co., Ltd. is one of the well-known China Industrial Ethylene Oxide Sterilizers manufacturers and Industrial Ethylene Oxide Sterilizers suppliers in China. We have our own technology development, design, production, sales and service department. Our products include the overall facilities of the ethylene oxide sterilization workshop, the pretreatment room, the ethylene oxide sterilizer, the analytical room and the ethylene oxide waste gas treat equipment. Our company has established in a quality management system which accordance with ISO9001:2008 and ENISO13485:2003/AC2009. Our company is engaged in: pretreatment - sterilizer - strong analytical --EO waste gas treatment, the whole process equipment manufacturing factory to provide custom Industrial Ethylene Oxide Sterilizers and wholesale Industrial Ethylene Oxide Sterilizers. We are a famous China Industrial Ethylene Oxide Sterilizers suppliers and Industrial Ethylene Oxide Sterilizers factory of ethylene oxide sterilization that uses hot air heating system in China, and had applied the "utility model patent certificate" (energy saving, water-saving, no corrosion, fast heating speed; which can extend the life of the equipment for 10-15 years). Our own FSTEO-WQ series of ethylene oxide waste air absorption and treatment equipment was developed with the domestic universities. It allows the low temperature reaction process and reselected the catalyst reacting under low temperature. The removal rate of the waste gas was more than 99.9% after the purification of the waste gas. The emission residual gas is far below the national standard requirements. We have also developed an automatic control system which can join the operation between the waste gas treat process and the sterilizing cabinet. Our technical engineers have decades of experience in the industry. So we can provide professional man to install, test, training or repair machine for customer. We have a large number of high-quality customers: Jiangsu Fresenius Medical Care (Germany), Nanchang Kelinnike Medical Appliance (Germany), Shenzhen DooJung Group (Korea), Nanjing micro-tech, Winner Medical and other well-known Pharmaceutical equipment or other related products enterprises in China. We can also provide you with the best equipment and services.

Customer Evaluation
l am very happy with everything and I want to congratulate you for an outstanding worker
l am very happy with everything and I want to congratulate you for an outstanding worker
l am very happy with everything and I want to congratulate you for an outstanding worker
l am very happy with everything and I want to congratulate you for an outstanding worker
you deserve it as you are excellent at your job and help me timeously with all my problems.
Leave a Message
If you have any questions, please leave us a message and we will reply to you as soon as possible
  • Name *
  • Email *
  • Country *
  • Telephone
  • Message *
  • Honor
    HO
    Business license
    HO
    Patent certificate
    HO
    Production License

    FIRSTEO
    Machinery News

    Industry knowledge

    What are the key features and advantages of industrial ethylene oxide sterilizers compared to other sterilization methods in the healthcare industry?

    Broad Compatibility: Ethylene oxide sterilization is compatible with a wide range of materials, including plastics, metals, rubber, glass, and electronics. This makes it suitable for sterilizing a variety of medical devices, instruments, and packaging materials.
    Penetration and Efficacy: Ethylene oxide has excellent penetrating power, allowing it to reach into complex and hard-to-reach areas of medical devices, ensuring thorough sterilization. It can effectively kill a broad spectrum of microorganisms, including bacteria, viruses, fungi, and spores.
    Low Temperature Sterilization: Ethylene oxide sterilization can be performed at relatively low temperatures (typically around 30-60°C), which helps preserve the integrity of heat-sensitive medical equipment, such as delicate instruments, electronic components, and certain plastics.
    Compatibility with Moisture-Sensitive Materials: Ethylene oxide sterilization is well-suited for moisture-sensitive materials that could be damaged by other sterilization methods, such as steam or high-temperature dry heat. It provides an effective sterilization option for items that are susceptible to warping, discoloration, or degradation in the presence of moisture.
    Scalability: Industrial ethylene oxide sterilizers are available in various sizes and configurations, allowing for scalability to accommodate different volumes of medical devices or products. This makes them suitable for small-scale sterilization operations as well as large-scale manufacturing facilities.
    Validation and Regulatory Compliance: Ethylene oxide sterilization processes have a long history of use and are well-established in the healthcare industry. The sterilization cycles can be validated and documented to comply with regulatory requirements and standards, ensuring the safety and efficacy of sterilized products.
    Shelf Life: Ethylene oxide has the advantage of providing a longer shelf life for sterilized products. It has the ability to inhibit microbial growth and prevent recontamination during storage, which is particularly important for products with extended shelf life requirements.
    Compatibility with Packaging: Ethylene oxide can penetrate many types of packaging materials, allowing sterilization of products within their sealed packages. This reduces the need for repackaging and minimizes the risk of contamination during handling and transportation.

    How does the use of ethylene oxide sterilizers impact the safety and efficacy of medical devices and pharmaceutical products?

    Effective Sterilization: Ethylene oxide is a powerful sterilizing agent that has the ability to penetrate various materials and kill a wide range of microorganisms, including bacteria, viruses, fungi, and spores. This ensures that medical devices and pharmaceutical products are effectively sterilized, reducing the risk of infections and ensuring their safety for use.
    Compatibility with Different Materials: Ethylene oxide sterilization is compatible with a wide range of materials commonly used in the healthcare industry, such as plastics, metals, rubber, glass, and electronics. This allows for the sterilization of diverse medical devices and pharmaceutical products without compromising their structural integrity or functionality.
    Preservation of Product Quality: Ethylene oxide sterilization is performed at relatively low temperatures, which helps preserve the quality and functionality of heat-sensitive medical devices and pharmaceutical products. This is particularly important for items that may be susceptible to degradation, warping, or discoloration when exposed to high temperatures or other sterilization methods.
    Validation and Regulatory Compliance: Ethylene oxide sterilization processes can be validated and documented to comply with regulatory requirements and standards, ensuring the safety and efficacy of sterilized medical devices and pharmaceutical products. This includes establishing and monitoring appropriate sterilization parameters, conducting validation studies, and implementing quality control measures.
    Extended Shelf Life: Ethylene oxide has the ability to inhibit microbial growth and prevent recontamination, which can contribute to extending the shelf life of sterilized medical devices and pharmaceutical products. This is crucial for products that require long-term storage or have extended expiration dates.
